FEATURES:
- Heavy duty motor for easy cutting
of hard wood and heavy work.
- Heavy steel cabinet body covering
all moving parts.
- Precision cast iron ground table and
extension wings on both sides of main table.
- Graduated front guide rail.
- All sealed precision ball bearing.
- Large hand wheels and lock for fast
movement and tilting.
- Mangetic control overload protection.
|
STANDARD ACCESSORIES:
- Aluminum fence and rails assembly.
- Arbor extension for saw blade.
- Miter gauge.
- Saw insert.
- Anti-kickback safety guard.
- Tool kit.
- Assembling and adjusting blocks for fence.
|
OPTIONAL ACCESSORIES:
- Sliding table assembly.
- T.C.T saw blade.
- Arbor extension for dado and dado insert.
- 72" rail for max. rip to right of blade.
- Clamping system for sliding table.
|
| SPECIFICATIONS |
SK-12TS |
SK-14TS |
SK-16TS |
| Saw blade diameter |
305mm / 12" |
355mm / 14" |
405mm / 16" |
| Max. depth of cut at 90 degree |
100mm / 4" |
125mm / 5" |
150mm / 6" |
| Max. depth of cut at 45 degree |
70mm / 2-3/4" |
89mm / 3-1/2" |
108mm / 4-1/4" |
| Arbor diameter |
30mm / 1" |
| Arbor speed |
4,000 RPM |
3,750 RPM |
3,750 RPM |
| Table size |
1220mm x 762mm |
1220mm
x 965mm ( 48" X 38" ) |
| Table height |
867mm ( 34-1/4"
) |
| Rail length |
1676mm ( 66" ) |
1981mm ( 78"
) |
| Max. rip to right of blade |
965mm ( 38" ) |
1245mm ( 49"
) |
| Motor |
3.75kw ( 5HP) |
5.6kw ( 7.5HP ) |
7.5kw ( 10HP ) |
| Packing size |
813 x 915 x 1067mm |
940 x 1118 x 1067mm |
940 x 1118 x 1067mm |
| |
32" x 36" x 42" |
37" x 44" x 42" |
37" x44" x 42" |
| N.W. |
259kgs ( 570 lbs ) |
386kgs ( 850 lbs ) |
395kgs ( 870 lbs ) |
| G.W |
318kgs ( 700 lbs ) |
459kgs ( 1,010 lbs ) |
470kgs ( 1,035 lbs ) |
| |
|
|
|
| |
|
|
|
|
